We has been providing a wide range of quality products, service and support to the application areas of superhard industry We fully integrate the resources of the superhard
25-year lifespan with near-zero maintenance reduces pipe network energy loss by 20%, detects flow anomalies instantly, and delivers trusted data for industrial & municipal operations.
1.Obstruction-Free Design:
Full-bore measurement with zero pressure loss for high-flow liquids.2.Superior Accuracy:
±0.5% with bidirectional flow detection.3.Corrosion Resistance:
316L SS & PTFE lining for wastewater, chemicals & slurries.4.IoT Ready:
4G/RS485/MODBUS protocols with 30-day data logging.5.Extreme Durability:
Operates in -25℃~+150℃ and IP68 for harsh environments.1.Industrial process monitoring (chemicals, pulp & paper)
2.Municipal water & wastewater systems
3.Marine fuel & ballast water measurement
4.Power plant cooling water monitoring
5.Hygienic sectors (food, pharmaceuticals)
|
DN. |
40 |
50 |
65 |
80 |
100 |
150 |
200 |
250 |
300 |
|
R |
160 |
160 |
160 |
160 |
160 |
160 |
160 |
160 |
160 |
|
Overload flow(m³/h) |
31.25 |
50 |
78.75 |
125 |
312.5 |
500 |
787.5 |
1250 |
2000 |
|
Service flow(m³/h) |
25 |
40 |
63 |
100 |
250 |
400 |
630 |
1000 |
1600 |
|
transitional flow-rate(m³/h) |
0.25 |
0.4 |
0.63 |
1 |
2.5 |
4 |
6.3 |
10 |
16 |
|
minimum flow(m³/h) |
0.16 |
0.25 |
0.4 |
0.63 |
1.6 |
2.5 |
4 |
6.3 |
10 |
|
Rated pressure |
1.0MPa(special pressure can be customized) |
||||||||
|
Temperature grade |
T50 |
||||||||
|
Diameter |
DN40~DN300(pipe flange type) |
||||||||
|
Electrode type |
standard fixed |
||||||||
|
Electrode |
316L |
||||||||
|
Flange |
Carbon steel,stainless steel |
||||||||
|
Body |
Carbon steel,stainless steel |
||||||||
|
Communication |
RS-485、RS-485、GPRS、NB-IOT |
||||||||
